Remote Video, Photo & Thermal Inspections

InspectBot

Our ready-to-deploy InspectBot solution allows for fast, robust & automated visual inspections, enabling people to be removed from hazardous environments.

Conduct Automated & Remote Inspections

Built to operate in isolated areas, providing real-time situational awareness and data

Scale your Operations Autonomously

Conduct On-Demand or Scheduled missions, operated via our global remote operating centres

Remove Staff from Harsh Environments

Let the InspectBot do all the hard work. Rated for operating temperatures between -35 and 50 deg. celcius.

Optional Maintenance & SLA

Hassle-free service options, conducted by OEM-approvedtechnicians, ensuring continuous up-timeand. Our cloud-based API allows you to trigger the drone for automated missions

Monitor Large & Remote Areas

Cover up to 25 sq. kilometres (10km straight-line) per xBot

Live Video Streaming & Analytics

Stream live video to your control centre or download static images for post-processing

Multiple Commercial Options Available

Our Purchase, Rent-to-Own or Fully-Managed solutions fit within your Opex or Capex budgets

Optional 24/7 Remote Operating Centre Availaibility

Always-on accessibility for customers that require continuous service.

SurveyBot Specs and Remote Operating Centre

Robust Hardware and Sensors

Deploy on-site 24/7 to suite your data application workflow

Wide Camera

  • 1/2” CMOS 12MP
  • Equivalent focal length: 24mm
  • 4k30fps video

Thermal Camera

  • 640x512@30Hz
  • Equivalent focal length: 40mm
  • R-JPG Images

Zoom Camera

  • 1/2" CMOS 48 MP
  • 5x-16x Optical Zoom
  • 200x Digital Zoom
  • 8k images and 4k30fps video

Laser RangeFinder (LRF)

  • 1200m detection range

Hardware Specifications

Automate your workflows using our proven mix of robust hardware & sensors
Dock
Product Name
DJI Dock 2
Total Weight
34 kg (without aircraft)
The actual product weight might vary due to differences in batch materials and external factors
Dimensions
Dock Cover Opened: 1228x583x412 mm (LxWxH)
Dock Cover Closed: 570x583x465 mm (LxWxH)
The above data does not include the height of the wind speed gauge (145 mm) but includes the height of the mounting base brackets (55 mm).
Input Voltage
100-240 V (AC), 50/60 Hzk 2
Input Power
Max 1000 W
Operating Temperature
-25° to 45° C (-13° to 113° F)
When the ambient temperature is below -20° C (-4° F), the dock is in standby status, and the aircraft cannot perform flight tasks.
Ingress Protection Rating
IP55
Max Operating Altitude
4000 m
Receiving Frequency of RTK Base Station Satellite
Simultaneously receive:
GPS: L1 C/A, L2
BeiDou2: B1l, B2l, B3l
BeiDou3: B1l, B3l
GLONASS: L1, L2
Galileo: E1, E5B
Positioning Accuracy of RTK Base Station
Horizontal: 1 cm + 1 ppm (RMS)
Vertical: 2 cm + 1 ppm (RMS)
Battery Capacity
12 Ah
Output Voltage
12 V
Battery Type
Lead-acid battery
Battery Life
> 5 hours
Product Name
DJI M3D or M3TD
Max Takeoff Weight
1610 g
DimensionsMax Wind Speed Resistance
During Operation: 12 m/s
During Takeoff/Landing: 8 m/s
Max Takeoff Altitude
4000 m
Max Flight Time
50 minutes
Measured in a controlled test environment. Specific test conditions are as follows: flying forward at a constant speed of 46.8 kph in a windless laboratory environment at 20 meters above sea level, in photo mode (without photo-taking operation during flight), with Obstacle Avoidance Action set to Off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.
Global Navigation Satellite System
GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when the RTK module is enabled.)
Hovering Accuracy Range (windless or breezy)
Vertical:
±0.1 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning:
Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning)
Operating Temperature
-20° to 45° C (-4° to 113° F)
Receiving Frequency of RTK Base Station Satellite
Simultaneously receive:
GPS: L1 C/A, L2
BeiDou2: B1l, B2l, B3l
BeiDou3: B1l, B3l
GLONASS: L1, L2
Galileo: E1, E5B
Ingress Protection Rating
IP54
DJI Matrice 3D
DJI Matrice 3TD
Wide-angle Camera
4/3 CMOS
24mm Format Equivalent
20MP Effective Pixels
Mechanical Shutter
1/1.32-inch CMOS
24mm Format Equivalent
48MP Effective Pixels
No mechanical shutter
Tele Camera
1/2-inch CMOS
162mm Format Equivalent
12MP Effective Pixels
56x hybrid zoom
1/2-inch CMOS
162mm Format Equivalent
12MP Effective Pixels
56x hybrid zoom
Thermal Camera
N/A
40mm Format Equivalent
28x Digital Zoom
↳ Normal Mode
640x512@30fps
↳UHR Infrared Image Mode:
1280x1024@30fps(With the UHR Infrared Image function enabled, the aircraft automatically enables or disables UHR Infrared Image mode according to the ambient light brightness.)
xBot® Upgrade Option includes additional functionality:
- 1080p HD PTZ Camera
- Weather Station
- Dual 5G Modem + Failover Redundancy (Starlink, WiFi, Wired)
- Additional LED Lighting
- Galvanised Skid Base
- Industrial Electrical Power Cabinet & Isolation Switches

Easy Deployment across your Operations

Cover multiple assets with our modular approach & global satellite coverage
Flight Time
40 min
Max. Operating Radius
5 – 7 km
Rapid Charging: 10% - 90%
25 min
Download our Case Study
Discover how RocketDNA deployed and tested its Surveybot to an actual customer site, helping to automate their on-site survey workflows.

Critical Asset Monitoring

Secure important assets such as bridges, dams and power stations with routine inspections and access areas where cameras and people cannot reach.

Thermal Inspections

Conduct daily thermal analysis to determine power loss estimates for critical sites or detect over-heating on large industrial assets

Autonomous Vehicle Monitoring

Provide an aerial view which supports your autonomous operations by reducing false positives and stoppages.

Our Process

Trust the industry-leader in delivering your remotely operated autonomous drone strategy

Initial Consultation

Chat with one of our experts to learn more about our xBot solutions

1
Determine which xBot fits your needs

Depending on Area Size, Data Output, Capture Frequency & Environmental factors, we can help you discover the perfect solution

2
Ordering & Assembly

Depending on Quantity, expect a Lead time of 4 - 6 weeks

3
On-Site Deployment & On-Boarding

Setup of Flight Missions, installation of xBot & Customer Training

4
Integration

Custom development and integration of operational triggers to allow for automated deployment

5

Related Projects

Who have we previously provided this product/service to?

No items found.

Frequently Asked Questions

01
How reliable is the xBot? What kind of extreme environments can it operate in?
02
What do I require on-site to operate a xBot?
03
How long does it practically take to deploy?
04
What is required with regards to Regulatory Approvals & Beyond Visual Line of Site?
05
Who is monitoring the drones and where are they located?
06
What Commercial models do you offer?
07
What integrations are available? How do I access and share my data?

Upgrade Options Available

Our xBot Platform has a modular design, allowing for customisation and integration to suite your requirements

Cloud-based AI Visualisation Platform
Cloud-based AI Visualisation Platform
Centralise all your visual data in our online platforms, allowing for further analysis & archiving
Custom Software Development & API Integration
Custom Software Development & API Integration
Trigger your xBot using our cloud-based API and automatically set GPS waypoints.
Global Data Satellite Connectivity
Global Data Satellite Connectivity
Using Starlink Business, we are able to deploy our xbots across the world to support your remote operations.
On-Site Maintenance SLA
On-Site Maintenance SLA
Guarantee up-time and performance with our on-site maintenance programme.
Dedicated Remote Operating Centre
Dedicated Remote Operating Centre
Deploy On-Demand with your own dedicated Flight Controller and Remote Operating Centre. Host your ROC at your premises or within our facilities.
Ready-to-Deploy Mine Spec Skid
Ready-to-Deploy Mine Spec Skid
Designed for harsh environments with high safety requirements, our ready-to-deploy skid includes electrical preconfiguration

Learn more about InspectBot

Discover how we can help your operations improve safety and reduce operational down-time
